G5 Series High Reliability Micro Switch
Max. Current:26A
Max. Voltage:48VDC, 125/250VAC
Operating Temperature:-25°C -+125°C
Protection Level:IP40
Operating Force:15gf - 400gf max.
Lever:Variety of Levers
Unit Net Weight:About 6.2g(No lever)
Voltage Resistance:AC1500V, 50/60HZ, 1min
Mechanical Service Life:10E4
Electrical Service Life:5E4
Insulation Resistance:100MΩ(500VDC) max.
Contact Resistance:50mΩ max.
Environment compliance:RoHS and Reach
-Tight Configuration,Small Contact Gap , Snap Action
-Long Life, High Reliability : 50,000cycles, 100,000 cycles optional.
-Variety of Terminals : Solder, PCB, Angle PCB, 187#, 250#, Screw terminals optional.
-Wide Range Operating Force: 15gf. 25gf, 50gf, 100gf. 150gf. 200gf. 300gf. 400gf max. optional.
-Wide Range Temperature Grade: -25°C -+85°C, -25°C -+125°C, -25°C -+150°C optional.
-With Optional PTI Grade: PTI175, PTI250 Optional.
-Variety Used in Home Applicances, Electronic Equipments, Automatic Machines,Communication Equipments.
-Variety of Levers : Hinge lever, Roller Lever. Straight Lever. Simulated Roller Lever. Pin Pluger etc.
| Place of Origin | Guangdong, China (Mainland) |
| Brand Name | Unionwell |
| Model Number | G5T16-D2P100-T021-U |
| Temperature Grade | 25T125 |
| Electrical Rating | ENEC/CQC 10(4)A 250VAC UL/CUL 16A 1/2HP 125/250VAC |
| Terminal style | 4.8*0.8mm quick connect |
| Circuit Code | SPST-NO |
| Operation force at pin plunger Max | 100gf 0.98N |
| Lever Position | / |
| Lever Type | / |
| Special Designator | T021 |
| Brand | Unionwell Brand |
