Waterproof IP67 Micro Switch 3A 250VAC Automotive Control System Subminiature Micro Switch
Max. Current:0.1A/3A
Max. Voltage:125/250VAC,48VDC
Operating Temperature:-40°C~+85°C
Protection Level:IP67
Electrical Life:Over 100,000 cycles
Mechanical Life:Over 500,000 cycles
Function:SPDT
Contact Resistance:100mΩMax
Insulation Resistance:100mΩ Min
Storage Humidity:85%RH Max
Certification:Rosh Reach
-Designed for water and dust tight(IP67)
-Small compact size
-Global safety approvals
-Long life and high reliability
-Variety of levers
-Wide range of wiring terminals
-Widely used in Automotive Electronics, Appliance and Industrial Control etc.
-Customized designs
| Rating | 0.1A,125/250VAC;3A/12VDC;0.1A/48VDC | |
| Operating Frequency | Electrical | 0.1A-120cycles/min; 3A-10~30cycles/min |
| Mechanical | 120cycles/min | |
| Contact Resistance(Initiative) | 100mΩMax | |
| Insulation Resistance | at500VDC,100mΩ Min | |
| Dielectric Strength | AC500V 50-60Hz 1min | |
| Vibration Durability | 10~55Hz | |
| Storage Temperature | -40°C~+85°C | |
| Storage Humidity | 85%RH Max | |
| Service Life | Electrical | Min.100,000cycles |
| Mechanical | Min.500,000cycles | |
