Unionwell waterproof switch 40T85 125 250 VAC 3A 0.1MA charging gun micro switch
Max. Current:3A
Max. Voltage:125V, 250V
Operating Temperature:-40℃-+85℃
Protection Level:IP67
IP level:ip67
Rating:0.1A/125VAC;3A/12VDC;0.1A/250VAC
Contact Resistance:100m Ohm Max
Insulation Resistance:100M Ohm Min
Operating force:130gf or 180gf
Electrical life:100,000cycles
Mechanical Life:Min.500,000cycles
Application:Auto Electronics
Product Name:Micro Swich
Color:Black
Keyword:Cherry Micro Switch
- The Unionwell G3 series mini waterproof switches are capable of withstanding currents from 0.1A to 3A and support voltages of 125/250VAC and 48VDC.
- With IP67 protection, the IP67 micro switch is designed to work stably even in harsh environments from -40°C to +85°C, ensuring reliable performance in harsh environments.
- G3 series mini waterproof switches is widely used in a variety of application scenarios such as automobiles, air conditioners, electric toothbrushes, toys and motor control.
-Designed for water and dust tight(IP67)
-Small compact size
-Global safety approvals
-Long life and high reliability
-Variety of levers
-Wide range of wiring terminals
-Widely used in Automotive Electronics, Appliance and Industrial Control etc.
-Customized designs
| Rating | 0.1A /125VAC; 3A/ 12VDC ; 0.1A /250VAC; 0.1A/ 48VDC u 1E5.Operating |
| Frequency Electrical | 0.1A-120/3A-10~30 cycles/minute |
| Operating Frequency Mechanical | 120 cycles/minute |
| Contact Resistance(Initiative) | 100mΩ Max |
| Insulation Resistance(at 500VDC) | 100MΩ Min |
| Vibration durability | 10~55Hz, move 0.75mm(p-p) |
| Dielectric Strength | 500VAC (50~60Hz) |
| Storage Temperature | -40℃-+85℃ |
| Storage Humidity | 85% RH Max |
| Service LifeElectrical | 6,000~500,000/cycles(Depend on part number) |
| Service Mechanical | Min.500,000/cycles |
