Model No: G9P1-200E01W1-G250U

Unionwell Sealed Waterproof Micro Switches for Automatic

Whether the smart:NO
Place of Origin:Guangdong, China
Brand Name:Unionwell
Model Number:G9P1-200E01W1-G250U
Max. Current:5A
Max. Voltage:250VAC
Operating Temperature:-25℃~120℃
Protection Level:IP67
IP level:IP67
Terminal Type:Wires leads from side (500mm)
Operating Force:300gf max w/o lever
Lever Type:Straight lever
Circuit Code:SPDT SPST-NC SPST-NO
Mechanical Life:500,000cycles
Electrical Life:100,000cycles
Certification:UL CE CCC
Application:Car
Rating:6A 125/250VAC
minimum order :
1000
Quantity :
Contact Now
Product Description

The G9P1 Sealed Waterproof Micro Switch for Automatic is a waterproof miniature micro switch specifically designed for automated control systems. It is widely used in various automated equipment, such as robots, production line equipment, and automated control systems. With its compact size and precise triggering performance, it provides an ideal solution for the automation field. This micro switch features a high-quality sealed design with an IP67 waterproof and dustproof rating, effectively preventing the intrusion of moisture, dust, and other external substances, thus ensuring stable operation in harsh environments. It is particularly suitable for long-term use in industrial automation control.

This automatic micro switch operates in a temperature range from -25℃ to +120℃, providing stable and reliable performance even under extreme temperature conditions. Its mechanical life reaches 500,000 cycles, and its electrical life is 100,000 cycles, ensuring long-term stable operation of the micro switch in automated equipment. Furthermore, its precise triggering design allows the switch to perform accurate operation and feedback in the control system, further improving the efficiency and safety of the automated control system.

As a subminiature micro switch, it is small in size but powerful in function, capable of working efficiently in confined spaces, and is widely used in limit detection, position control, overload protection, and other applications in automated equipment. Designed by a micro switch manufacturer, this subminiature micro switch has become an indispensable core component in modern industrial automation, suitable for various application environments requiring high durability and high reliability.

Feature
◆ Waterproof and dustproof (IP67) design
◆ Small size and compact structure
◆ Long life and high reliability
◆ Complete terminal block selection
◆ Equipped with various operating handles
◆ Widely used in automotive, home appliance, and industrial control applications

Advantages

  • Wide operating range: maximum load current of 5A, rated voltage of 250VAC, and stable operation in a temperature range of -25°C to +120°C.
  • Sealed and waterproof: This is an IP67-rated Waterproof Micro Switch that is resistant to water and dust, ensuring stability in harsh environments.
  • Meets safety standards: The switch is certified to several safety specifications, such as UL, CE and IATF16949.
The G9 Series Sealed Waterproof Micro Switch is widely used in automotive control systems and plays an important role in the production of automobiles, and its superior performance and competitive price have become the first choice of many car manufacturers around the world.

Parameter

Rating
P1
ENEC: 0.1A 125/250V 48VDC 5E4

Gold Plated Contact Optional
,05
ENEC:5A 125/250VAC
10
ENEC :10(2)A 125/250 VAC u25T125

NOTE:only with"OF"over"250gf"
Operating Frequency
Electrical
10-~30 cycles/minute
Mechanical
120 cycles/minute
Contact Resitance
100MΩ Max
Insulation Resistance
( at 500VDC)
100MΩ Min
Dielectric Strength
AC 1,000V RMS (50~60Hz)
Storage Temperature
(-40°C~ +125°C/85°C)
Storage Humidity
85% RH max
Service Life
Electrical
10,000~100,000cycles
(Depend on part number)
Mechanical
1,000,000cycles

 Drawing

sealed micro switch

Application

Designed specifically for automated control systems, this waterproof subminiature micro switch is widely used in the precision control of automated equipment. It boasts exceptional stability and durability, making it suitable for various automated control devices such as automated machinery, robots, and production line equipment.

The switch features a sealed design with an IP67 waterproof rating, effectively preventing the intrusion of moisture and dust, ensuring stable operation even in humid or dusty environments. Its dustproof performance is equally excellent, guaranteeing long-term use in industrial environments unaffected by external conditions.

Furthermore, the Unionwell G9P1 Sealed Waterproof Micro Switch's precise triggering characteristics enable fast and reliable responses in automated control, making it widely used in limit detection, overload protection, and other functions in automated control systems. Maintaining excellent performance within a temperature range of -25℃ to +120℃, this micro switch significantly enhances the reliability and safety of automated control systems.
