Unionwell DPDT Push Button Micro Switch For Car Window

Max. Current:5A
Max. Voltage:250VAC
Operating Temperature:-25℃~125℃, -25℃~125℃
Protection Level:IP40 IP67
Product Name:double pole double throw switch car window mini micro switch
Payment Terms:T/T,Western Union
Terminal Type:Wires leads from side (500mm)
Operating Force:300gf max w/o lever
Lever type:Straight lever
Circuit Code:SPDT SPST SPST-NC SPST-NO
Housing material:PET, 94V2

Quantity :

Contact Now

Products Description

Sealed Mini micro switch also is a push button switch for car window with dust and water proof design (IP67). Its small and compact design allows it to provide reliability to enhance the performance of automotive control systems even in a compact space. The G9 series sealed micro switch is also a high-performance DPDT micro switch that enables multi-loop control for advanced functions such as window anti-pinch safety. As a window push button switch, it can withstand temperature extremes from -25°C to 125°C, while it is IP40 and IP67 rated for protection against dust, moisture and vibration in door assemblies.

Unionwell, as a leading micro switch manufacturer in China, we produce microswitches that support SPDT, SPST-NO/NC and DPDT configurations for a variety of automotive and industrial applications. Meanwhile, our products meet international safety standards and support T/T and Western Union payment methods for worry-free transactions.

Parameter

Rating	P1	0.1A 125/250VAC 48VDC/Gold Plated Contact Optional
Rating		05	UL:5A 125/250VAC ENEC:6A 125/250 1E4;3A 125/250VAC 30VDC 5E4 µ 25T120
Operating Frequency	Electrical	10~30cycles/minute
Operating Frequency		Mechanical	120cycles/minute
Contact Resistance(Initiative)			100mΩMax/It depends on the wire length for the type with wire
Insulation Resistance (at 500VDC)			100M Ω Min
Dielectric Strength			AC1,000V RMS (50~60Hz)
Storage Temperature			-25°C~+120°C
Storage Humidity			85%RH Max
Service Life	Electrical	10,000cycles/Depend on part No.
Service Life		Mechanical	500,000cycles

Drawing

Unionwell sealed mini micro switch for car windows

Applications

As a micro switch for car windows,the DPDT micro switch activates dual circuits when the driver presses the window adjustment push button switch, one circuit to smoothly raise the window, and the other to stop the movement as soon as an obstacle is detected (anti-pinch function). Its IP67-rated sealing ensures flawless performance even in the rain or during car washes, while the PET housing protects against UV exposure and chemical cleaners.In addition, the sealed mini micro switches can be used in environments that require water and dust resistance, such as industrial machinery, household appliances and electric vehicle charging units.
