Unionwell Micro Switch Manufacture Sealed Slide Switch For Automotive 0.1A 12VDC
Max. Current:20mA
Max. Voltage:12V DC
Mechanical Life:300000 cycles
Company assurance system:ISO9001 & TS16949
Environmental compliance:RoHS, Reach
Rating:0.1A 12VDC
Electrical life:100,000cycles
Color:Black
Mechanical life:100,000cycles
Operating force:150gf max w.o lever
Function/circuit:SPDT (NO or NC for option)
Terminal type:PCB terminals (others for option)
- The Unionwell G3 series mini waterproof switches are capable of withstanding currents from 0.1A to 3A and support voltages of 125/250VAC and 48VDC.
- With IP67 protection, the IP67 micro switch is designed to work stably even in harsh environments from -40°C to +85°C, ensuring reliable performance in harsh environments.
- G3 series mini waterproof switches is widely used in a variety of application scenarios such as automobiles, air conditioners, electric toothbrushes, toys and motor control.
-Designed for water and dust tight(IP67)
-Small compact size
-Global safety approvals
-Long life and high reliability
-Variety of levers
-Wide range of wiring terminals
-Widely used in Automotive Electronics, Appliance and Industrial Control etc.
-Customized designs
Rating | 0.1A 125/250VAC;3A/12VDC;0.1A/48VDC | |
Operating frequency | Electrical | 0.1A-120;3A-10~30 cycles/min |
Mechanical | 120 cycles/min | |
Contact resistence | 100M Ω Max(without wire type) | |
Insulation resistance | 100M Ω Min | |
Vibration durability | 10~55Hz, move 1.5mm(p-p) | |
Dielectric Strength | 500VAC (50~60Hz) | |
Storage Temperature | -40℃+85℃ | |
Storge Humidity | 85% RH Max | |
Service | Electrical | Min 100,000 cycles |
Mechanical | Min 500,000 cycles | |
