Mechanical Waterproof 12V 40T85 Micro Switch For Car
Protection Level:IP67
Max. Current:15A
Max. Voltage:380V
LED:NO
Product name:Mechanical waterproof 12V 40T85 micro limit switch for car
Electrical life:50,000cycles
Mechanical life:1,000,000cycles
Function/circuit:SPDT (or SPST-NO, NC for option)
Lever type:Straight lever
Operating force:50gf max w/ lever (light or heavy for option)
Company assurance system:ISO9001 & TS16949
Environmental compliance:RoHS, Reach
Terminal type:Solder terminals (other types for option)
-Small compact size
-Global safety approvals
-Long life and high reliability
-Variety of actuator and terminals
-High rating to 10(2)A,1/4Hp
-Customized designs
-Widely used in auto control ,applicance control ,industrial control etc.
Parameters
| Rating | 0.1A /125VAC; 3A/ 12VDC ; 0.1A /250VAC; 0.1A/ 48VDC u 1E5. | |
| Operating Frequency | Electrical | 0.1A-120/3A-10~30 cycles/minute |
| Mechanical | 120 cycles/minute | |
| Contact Resistance(Initiative) | 100mΩ Max | |
| Insulation Resistance(at 500VDC) | 100MΩ Min | |
| Vibration durability | 10~55Hz, move 0.75mm(p-p) | |
| Dielectric Strength | 500VAC (50~60Hz) | |
| Storage Temperature | -40℃-+85℃ | |
| Storage Humidity | 85% RH Max | |
| Service Life | Electrical | 6,000~500,000/cycles(Depend on part number) |
| Mechanical | Min.500,000/cycles | |
FAQS
Who are we?
We are based in Guangdong, China, start from 2007,sell to Domestic Market(60.00%),Southern Europe(14.00%),NorthAmerica(13.00%),Southeast Asia(8.00%),Western Europe(3.00%),Northern Europe(2.00%). There are total about 301-500 people in our office.
How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
What can you buy from us?
We have a wide range of products and a large amount of stock in stock, such as Micro Switch; Automotive switches; Waterproof switches; Pressure switches; Mechanical keyboard switches.With independent research and development laboratory, we can provide customized services according to your needs.
Why should you buy from us not from other suppliers?
Factory ISO9001 & IATF16949 qualified Products are produced & tested by automatics;
Own team designed and assembled automatic machines ;
Awarded as National Innovative Technology ;
Company authorized over 100 Patents.
What services can we provide?
Accepted Delivery Terms: FOB,EXW,FCA,Express Delivery;
Accepted Payment Currency: USD, HKD, CNY;
Accepted Payment Type: T/T,Western Union,Cash;
Language Spoken:English,Chinese.
