G3 Series Electric Waterproof Switch for Automotive 3 pins 0.1A 12VAC
Protection Level:IP67
Max. Current:10A, 15A
Max. Voltage:250VAC
LED:NO
Switch Combination:1NO1NC
Product name:Waterproof Micro Switch for Automotive Switch Application
Electrical life:50,000cycles
Mechanical life:1,000,000cycles
Function/circuit:SPDT (or SPST-NO, NC for option)
Lever type:Straight lever
Operating force:50gf max w/ lever (light or heavy for option)
Company assurance system:ISO9001 & TS16949
Environmental compliance:RoHS, Reach
Terminal type:Solder terminals (other types for option)
Certification:ENEC,ISO,CQC,RoHS, REACH
- The Unionwell G3 series mini waterproof switches are capable of withstanding currents from 0.1A to 3A and support voltages of 125/250VAC and 48VDC.
- With IP67 protection, the IP67 micro switch is designed to work stably even in harsh environments from -40°C to +85°C, ensuring reliable performance in harsh environments.
- G3 series mini waterproof switches is widely used in a variety of application scenarios such as automobiles, air conditioners, electric toothbrushes, toys and motor control.
- -Designed for water and dust tight
- -Small compact size
- -Global safety approvals
- -Long life and high reliability
- -Wide range of wiring terminals
- -Widely used in automotive electronics, appliances, and industrial control.
- -Customized designs
| Operating Speed | 1~500mm/s | |
| Operating Frequency | 120 cycles/min | |
| Insulation Resistance | 100MΩ Min | |
| Contact Resistance(initiative) | With Terminals Type | 100mΩ Max |
| Voltage Resistance | Between Terminals | AC500V,50/60HZ,1min |
| Between Terminals And Uncharged Metal Parts | AC1000V,50/60HZ,1min | |
| Vibration Resistance | No Transformation Action | 10-55 HZ |
| Service Life | Electrical | 300,000/cycles(20 cycles/minute) 12VDC 0.1A 5VDC 50μA |
| Mechanical | 300,000/cycles(30 cycles/minute) | |
| Storage Temperature | -40°C~+85°C | |
| Storage Humidity | 85%RH Max | |
