Unionwell Subminiature Micro switch 3A 125VAC
Max. Current:3A
Max. Voltage:125V
Operating Temperature:-40℃~+85℃
Electrical life: 10,000/50,000 cycles (Depend on Part No.)
Operating force:150gf
Lever type:More options
Product name:Snap Action Micro Switch with Hinge Lever
Mechanical life:1,000,000cycles
Terminal:Variety
Application:Cleaner
Color:black & white
As a reliable home appliance micro switch, this micro switch demonstrates exceptional adaptability in practical applications. It operates continuously over a wide operating temperature range of -40°C to +85°C, ensuring stable operation of home appliances in both cold and hot environments. This feature makes it particularly suitable for appliances subjected to long-term use, providing stable and reliable performance, whether undergoing daily start-up and shutdown or high-frequency operation.
In terms of durability, this micro switch boasts an electrical lifespan of 50,000 cycles (depending on part number) and a mechanical lifespan of up to 10,000,000 cycles, ensuring precise and sensitive triggering performance even under prolonged, high-frequency operation. Furthermore, its lightweight design, with a unit weight of 0.5g, adds virtually no additional burden during installation and integration, making it ideally suited for the demands of modern miniaturized home appliances.
Overall, the G10 Subminiature Micro Switch, designed by a micro switch manufacturer, offers an efficient, stable, and long-lasting control solution for home appliances with its compact size, wide temperature adaptability, and exceptionally long service life, making it an ideal switch choice for enhancing appliance reliability and performance.
◆ Long life and high reliability
◆ Complete terminal range
◆ Equipped with various operating handles
◆ Widely used in home appliances and industrial control
| Rating | P1 | ENEC/CQC: 0.1A 48VDC/125VDC |
| UL/CUL: 0.1A 48VDC/125VDC | ||
| 3 | ENEC/CQC: 1A/3A 125VAC | |
| UL/CUL: 1A/3A 125VAC | ||
| Operating frequency | electrical | 10~30 cycles/min |
| mechanical | 120 cycles/min | |
| Contact resistance (initial value) | 100mΩ Max（Depends on the NO.） | |
| Insulation resistance | 100MΩ Min.(at 500 VDC) | |
| Dielectric strength | Between terminals | 600VAC 50~60Hz for 1 Min. |
| Terminals and housing | 1000VAC 50~60Hz for 1 Min. | |
| Operating environment Temperature | -40℃~+85℃ | |
| Operating environment humidity | %85RH Max. | |
| lifespan | electrical | 10,000/50,000 cycles(Depends on the NO.) |
| mechanical | 1,000,000 cycles | |
| Unit weight | about 0.5g(Straight PCB without handle type) | |
In terms of electrical performance, this micro switch boasts a maximum voltage rating of 125VAC, 48VDC, making it suitable for a wide range of home appliance circuits. It operates stably in a wide operating temperature range of -40°C to +85°C, making it suitable for use in environments subject to significant temperature fluctuations, such as kitchens and living rooms.
Durability is a key feature of this switch. With an electrical life of 50,000 cycles (depending on part number) and a mechanical life of 10,000,000 cycles, it maintains long-term reliability even in high-frequency home appliances. Furthermore, its lightweight design, with a unit weight of 0.5g, allows for easy integration into small, space-constrained appliances without adding bulk.
