Unionwell hot selling 0.1A SPDT charging gun charging pile micro switch

• Place of Origin:Guangdong, China
• Brand Name:Unionwell
• Model Number:G10B
• The G10 Micro Switch is an electrical component with excellent performance that is suitable for a wide range of applications. The Micro Switch has excellent technical characteristics that ensure reliability and stability in a wide range of environmental conditions.
• The maximum current of this product (G10B) is 1A, and the maximum voltage can reach 125VAC, which is suitable for a variety of application scenarios such as household appliances, telephones, electrical equipment, and testing machines. Its wide operating temperature range from -40°C to +85°C makes it capable of operating in a wide range of harsh environments. In addition, its IP67 rating guarantees stable operation in wet or dusty environments.
• Electrical life can vary depending on the product model, ranging from 6,000 to 100,000 cycles. The mechanical life is up to 1,000,000 cycles (5,000,000 cycles optional) to ensure long-term stable use. Rated at 0.1A/3A 125VAC and 48VDC, it is able to meet a variety of electrical requirements.
• The operating force can be selected according to the requirements, including 30gf, 50gf, 100gf and 150gf, to adapt to different operating environments. The terminals are directly PCB connected for easy installation and connection.
• This
  gun micro switch has a variety of functions, including Single Pole Double Throw (SPDT), Single Pole Single Throw-Normally Open (SPST-NO), and Single Pole Single Throw-Normally Closed (SPST-NC) to meet the needs of different application scenarios. The leverage type is an analog roller lever, which has high reliability.
• The G10B micro switch has passed the ISO9001 and TS16949 quality certification, and the quality is reliable.

-Small Compact Size

-Global safety approvals

-Long life and High Precision and Reliability

-Variety of levers optional

-Variety of Terminals

-Widely used in Car, Charging Pile, Charging Gun
