Unionwell Refrigerator Door Light Switch SWP-SEL-01-A001U
Max. Current:0.5A
Max. Voltage:24VDC
Operating Temperature:-25℃~+60℃
Protection Level:IP00
Electrical life:100,000 cycles
Mechanical life:200,000cycles
Rating:0.25A 250VAC 0.5A 24VDCC 12vdc 48VDC
Terminal:Solder terminals
Function:SPST-NO
Application 1:Auto Electronics, Door Lock switch, Door Open Switch
Application 2:Industry Control switch, Telecommunications Cabinet door control
Color:White
Product Name:Refrigerator switch
- SWP-SEL-01-A001Urefrigerator door light switch is the ideal choice light switch for refrigerator door.
- The refrigerator door light switch has a standard current rating of 0.5A, a rated voltage of 24VDC, IP00 protection, and a wide range of operating temperatures from -25°C to +125°C, ensuring that the micro switch can work stably in various environments.
- The longevity of the refrigerator door light switch is guaranteed by an electrical life of 100,000 cycles and a mechanical life of 200,000 cycles.
- Built-in SPST-NO function, white simple appearance, solder terminals to ensure secure installation.
- And it has a wide range of applications, whether it is used in automotive electronics, door lock switches, door switches, or industrial control switches and telecom cabinet door control, SWP-SEL-01-A001U refrigerator door light switch can meet your various needs.
- Unionwell is a micro switch expert around you, and also provides you with micro switch customization services!
item | value |
Certification | ENEC,CQC |
Whether the smart | NO |
Place of Origin | China |
Guangdong | |
Brand Name | Unionwell |
Model Number | SWP-SEL-01-A001U |
Max. Current | 0.25A 0.5A |
Max. Voltage | 125VAC 24VDC |
Operating Temperature | -25℃~+60℃ |
Protection Level | IP40 |
Electrical life | 100,000 cycles |
Mechanical life | 200,000cycles |
Rating | 0.1A 0.25A 0.5A 1A 5A 10A 16A 22A 26A 125VAC 250VAC 12vdc 48VDC |
Terminal | PCB Solder Screw and 187# 250# Wire leads terminals |
Function | SPST-NC |
Application 1 | Auto Electronics, Door Lock switch, Door Open Switch |
Application 2 | Industry Control switch, Telecommunications Cabinet door control |
Color | White |
