Unionwell GT06 Quiet Mechanical Keyboard Switch 3.5±0.2mm Travel

Brand Name:Unionwell
Model Number:GT06 series
Max. Current:10mA
Max. Voltage:12 VDC
Operating Temperature:-40℃ ~+80℃
Product name:mechanical keyboard switch
Type:Coin Operated Game Machines
Mechanical Life:80,000,000 cycles
Application:computer keyboard
Related words:linear, soft tactile
Color:yellow
Keyword:mechanical keyboard switch
Electrical life:80,000,000 cycles
Feature:light guide column light guide,soft light

minimum order :

1 piece

Quantity :

Contact Now

Product Description

The GT06 Silent Mechanical Keyboard Switch (3.5±0.2mm travel) is a mechanical keyboard switch， designed by a micro switch manufacturer specifically for a high-quality typing experience. This mechanical keyboard switch features a pale yellow POM base with a positioning post and pocket, a matte white POM rubber cover, and a pink POM rounded wall. Combined with a 30gf stainless steel spring and light guide, it delivers a smooth key travel and a light, tactile feel. The switch's robust construction provides a soft, precise feel, making it ideal for extended typing or office use.

As a gaming keyboard switch, the GT06 is characterized by its robust construction, low-pitched sound, and responsive bottoming-out. By optimizing its internal mechanical structure, it achieves a more stable and gentle click sound while maintaining a crisp tactile feedback, ensuring accurate and fast actuation even in the most intense of situations. Whether playing rhythm games or high-speed typing, the GT06 delivers a quiet and smooth control experience.

Thisquiet mechanical keyboard switch operates reliably in temperatures ranging from -40°C to +85°C and maintains humidity levels up to 85% RH. Its electrical and mechanical lifespans are both rated at 80 million cycles, ensuring long-term durability and consistent performance. Leveraging premium POM material and precision manufacturing, the GT06 maintains exceptional silence while still delivering a responsive, consistent, and richly textured keystroke, making it an ideal choice for both office and gaming use.

Feature

◆ Reliability (no mechanical or electrical degradation, extremely long life) & hot-swappable
◆ Versatility (connection and disconnection points can be different)
◆ Multiple connection points (different numbers of positions can be reported, depending on the IC)
◆ Adjustable multiple connection points during travel, TriggerMax™: Dynamic contact adjustment
◆ Robustness: Easy waterproofing
◆ 250μs response time
◆ Analog behavior
◆ Fully customizable keyboard: Different key profiles can be used for different purposes, such as gaming and word processing

Parameter

Operating force	30gf/40gf
Total journey	3.5±0.2mm
Full stroke pressure	<85gf
Mechanical life	>80,000,000 cycles
Operating temperature	-40℃~+80℃
Operating humidity	≤85%RH

Drawing

This product is mainly customized, so there are many styles and they are different. No specific drawing is provided for the time being.

Application

The GT06 Quiet Mechanical Keyboard Switch 3.5±0.2mm Travel is a high-quality mechanical switch designed for computer keyboards, focused on providing a quiet, stable, and responsive typing experience. Its unique structural design ensures a firm, tactile feel with each keypress, ensuring comfort and focus during extended typing or office work.

Featuring a stable base, a low-pitched sound, and a sensitive bottoming-out feedback, this switch effectively reduces typing noise, making it ideal for office and gaming keyboards where both quietness and tactile feel are paramount. Whether for fast typing or precise control, the GT06 ensures precise signal transmission and smooth response.

In terms of performance, it boasts an operating temperature range of -40°C to +85°C and an electrical and mechanical lifespan of up to 80,000,000 cycles, demonstrating exceptional durability and consistency. Furthermore, its maximum operating humidity reaches 85%RH, making it adaptable to a variety of challenging environments. The GT06 silent mechanical switch is the ideal choice for users who pursue the ultimate input experience and reliable quality.
