G1 Series Active Sealed Tact Switch
Rating: 12VDC 20μA~20mA
Model Number:G1 series G17 Series
Electrical life:100,000 cycles
Mechanical Life:100,000 cycles
Operating Environmental Humidity:85%RH Max.
Electrical Operating Frequency: 20 cycles/min.
Mechanical Operating Frequency: 120 cycles/min or 80 cycles/min.
Product name:waterproof tact switch
Operating Temperature: -40℃~+85℃
Unit Weight: 0.85g or 1.1g
In automotive control systems, this tact switch, with its ultra-compact design, can be flexibly integrated into space-constrained modules. Its mechanical life exceeds 100,000 cycles, maintaining excellent durability even under frequent operation, meeting the long-term needs of automotive use.
Simultaneously, this product is also suitable for human-machine interfaces and control panels in industrial equipment. As an industrial control micro switch, it can operate stably in environments with a maximum humidity of 85%RH, making it suitable for automated equipment and control terminals. The overall solution is meticulously designed by the micro switch manufacturer, achieving a good balance between performance, size, and reliability.
◆ Long lifespan and high reliability
◆ 0.8*0.8 PCB terminals
◆ Safe operation design requiring simultaneous operation of both handles for power-on
◆ Available with various handles and control methods
◆ Ultra-compact size, suitable for confined spaces
| Rating | 12VDC 20μA~20mA | |
| Operating Frequency | Electrical | 20 cycles/min. |
| Mechanical | G1 Series: 120cycles/min. | |
| G17 Series: 80cycles/min. | ||
| Initial Contact Resistance | <200mΩ | |
| Insulation Resistance | ＞10MΩ | |
| Vibration Resistance | 10~55Hz, Amplitude 1.5mm | |
| Withstand Voltage | Between Terminals | 500VAC(50~60Hz) |
| Between Terminals and Housing | 1500VAC(50~60Hz) | |
| Lifespan | Electrical | 100,000 cycles |
| Mechanical | 100,000 cycles | |
| Operating Environmental Temperature | -40℃~+85℃ | |
| Operating Environmental Humidity | 85%RH MAX | |
| Unit Weight | G1 Series | 0.85g |
| G17 Series | 1.1g | |
